If you are willing to find a useful and nice antenna, this 50W Outdoor Hanging Antenna for Cell Phone Signal Booster (800-2500MHz) will be the best chance you can have a try . For 2-3 meters, an interior without blocking range below 300 square meters is equipped with 1 antenna for 300-500 square meters, range of the Outdoor Hanging Antenna 500-800 square meters to 3 antennas installed. Amazing 50W Outdoor Hanging Antenna, by pointing the direction of antenna to the company can launch stations, the best Antenna can receive omni-directional antennas by indoor height of installation, to achieve the best effect.Small Cheap Antenna with great use, do not miss the 50W Outdoor Hanging Antenna(800-2500MHz), you will like the way it works!

Here you go, take the chance to get the best product with reasonable price.

At a Glance:

• Range 500-800 square meters to 3 antennas installed
• 800-2500MHz 50W Outdoor Hanging Antenna provides brighter, more accurate colors and sharper images
• Outdoor Hanging Antenna ensures maximum signal transfer and accurate signal load to all outlets
• This 800-2500MHz 50W Outdoor Hanging Antenna does it's job, splitting the signal precisely
• Distribution: outdoor antenna BaMu directional antenna, by the direction of antenna pointing to the company can launch stations, in order to achieve the best effect
• Best Antenna can receive omni-directional antennas by indoor height of installation, for 2-3 meters (the Cheap Antenna installation quantity and position and indoor area and indoor structure), an interior without blocking range below 300 square meters only install 1 antenna 300-500 square meters


Specifications:

• Frequency range:800-2500MHz
• Gain ( dB):Uplink  7DB
• I/O impedance:50Ω/N connector
• Ambient temperature:-10°C ~ 60°C
• Size:200 x 180 x 30 mm/ 7.9 x 7.9 x 1.2in(L x W x H)
• Power:50W
• Joint model:N-female
• VSWR:1:1.3

Product Notes:

• Fix up outdoor antenna reception on housetop and point to signal tower
• Connect outdoor antenna to ''outdoor'' port in repeater machine through cable
• Connect indoor antenna(s) to ''indoor'' port in repeater machine through cable also
• Plug power adaptor into AC power socket and finish installation
• If still no signal receipt after activated booster, please check if outdoor antenna point to signal tower or elsewhere have strong signal and check if strength achieve -70DBM.
• Please adjust the direction of outdoor antenna if it cannot call out
• If strength is not steady, please check if outdoor and indoor antenna are too close. Please ensure the outdoor and indoor antenna have distance of 20 meters at least ,with a wall between and net a same horizontal line
• The distance between the outdoor antenna and the amplifier is not more than 30 meters
• The outdoor Antenna not close to a large antenna, high-voltage lines, transformers, or metal mesh, etc.
• The distance between the indoor antenna and the amplifier is not more than 40 meters
• The indoor antennas do not close to the wall as far as possible in order to increase the coverage area
• The indoor antenna and the outdoor antenna are advised to stay away from each other for If lack of communication quality, please change the installation position of the outdoor antenna and adjustment the indicate direction of antenna
• It is best to enclose waterproof tape at the junction, and prevent moisture narrow the indoor signal coverage area
• Try to straight the cable, do not bend more than 90 degree

Accessories:

• 50W Outdoor Hanging Antenna(800-2500MHz)
