6 Bands High Power Prison 2G WiFi Signal Jammer up to 150 M
It was developed specially for prisons and other large sensitive locations such as military or governmental compounds.
This high power system has been approved and installed by Prison Authorities in very large prison facilities in several Countries world wide.
Technique characteristics
Taking use of UHF interference technology, support 3G and long-distance warn.
Effective power high, jamming radius is long.
Imported elements: Slow start up design of circuit. These elements can maintain the stable operation condition with high integration.
Optional Features
Selection of antennas to provide more flexibility regarding jamming coverage.
Special additional housing for all weather protection.
Can use the UPS and battery
| Band | Band | frequency | output power |
| 1 | GSM | 925-960 MHz | 30W |
| 2 | DCS | 1805-1880 MHz | 30W |
| 3 | 3G | 2110-2170 MHz | 25 W |
| 4 | 4G1LTE | 790-826MHz(EU standard) or 725-770 MHZ(US standard ) | 30W |
| 5 | 4G Wimax | 2620-2690 MHz (EU standard) or 2345-2400 MHZ (US standard) | 25 W |
| 6 | Lojack | 165-174 MHz | 25 W |
| optional frequency: VHF/25w, UHF/25w, RF315MHz/25w, RF433MHz/25w, RF868MHz/30w, 1170-1280MHz/25w, 1370-1390MHz/25w, WIFI 5.2G: 5100-5680MHz/10w, WIFI 5.8G: 5680-5900MHz/10w, 5G 3.5G cell phone: 3400-3600MHz/25w, 5G 3.7G cell phone: 3600-3800MHz./25w. | |||
| 1 Number of Antennas: 3 2 Cooling cooling system: Yes, it also has heatsinks 3 Power supply: If it has a 220V source 4 Locking angle: 90 ° vertical and 65 horizontal 5 Operating temperature: -20 to 60 ° 6 Antennas: Reinforced plastic for at least any type of weather condition 7 Operability time: Constant 24 * 7 8 Installation: Adherence to the walls by high resistance metal supports. 9 Remote control software: no account with assistance or control remotely 10 Functionality: Equipment designed for external use 11 Power regulator: It has power control to adjust the inhibition coverage on the area of interest. 12 Number of transmission modules: 6 transmission modules for a total of 7 output bands |
|||
| Waterproof: IP 65 | |||
Includes:
3 Antennas
6 Cables Antennas
1 Cable 110/220V Conection
1 Jammer
1 User Guide and video
